Millimeter wave radar human body sensor principle Human body sensor switch scheme

2024-07-24 217

I. Introduction


In the fields of smart home, security monitoring, automation and control, human body sensing technology plays a crucial role. As a new kind of human body sensing technology, millimeter wave radar human body sensor is gradually favored by the market for its high sensitivity, high anti-interference and all-weather working characteristics. This paper will discuss the principle of millimeter wave radar human sensor in detail, and the human sensor switch scheme based on the principle.

雷達(dá)成品飛睿智能

Second, the principle of millimeter wave radar human body sensor


Millimeter wave radar human body sensor mainly uses electromagnetic waves in millimeter wave band to detect human body. Millimeter wave refers to electromagnetic waves with wavelengths between 1 mm and 10 mm. Millimeter wave radar transmits millimeter wave signals and receives the signals reflected back by the human body. Through signal processing and analysis, it realizes the perception of the existence of the human body.


The working principle of millimeter wave radar human body sensor mainly includes the following steps:


Signal emission: An oscillator inside the millimeter wave radar sensor generates a high-frequency millimeter wave signal, which is transmitted through the antenna.


Signal propagation and reflection: The emitted millimeter wave signal propagates in space, and when it encounters the human body, some of the signal will be reflected back by the human body.


Signal reception and processing: The reflected MMwave signal is received by the antenna of the radar sensor, and is amplified and filtered by the internal receiving circuit. The signal is then fed into the signal processing unit for further digital signal processing.


Human presence judgment: By comparing the difference between the transmitted signal and the received signal, the millimeter-wave radar sensor can determine the presence or absence of the human body. This judgment is usually based on the comprehensive analysis of Doppler effect, signal strength change, phase difference and other parameters.


Third, millimeter wave radar human body induction switch scheme


Based on the principle of millimeter wave radar human sensor, we can design an efficient and stable human sensor switch scheme. The scheme can be widely used in lighting, security, automatic control and other fields to realize the human body induction control function.


Hardware design

The hardware part of the human body sensor switch mainly includes millimeter wave radar sensor module, microcontroller, power module and control output module. The millimeter wave radar sensor module is responsible for detecting the presence of the human body, and the microcontroller is responsible for receiving the sensor signal and controlling the output module. The power module provides a stable power supply for the entire system.


In hardware design, it is necessary to fully consider the sensitivity, anti-interference ability and working range of the sensor. At the same time, the selection of microcontrollers should also take into account the processing speed, power consumption and scalability.


Software design

Software design is the core of human body induction switch scheme. The data acquisition, processing and control output of millimeter wave radar sensor are realized by writing corresponding program.


In the process of software design, it is first necessary to configure the parameters of the millimeter wave radar sensor, such as transmission power and receiving sensitivity, to ensure that the sensor can detect the human body stably. Secondly, it is necessary to write a signal processing algorithm to filter, amplify and digitize the received signals to extract the characteristic information of the human body. According to the extracted feature information, determine whether the human body exists, and control the output module to perform the corresponding operation.


In order to improve the stability and reliability of the system, anti-interference measures, misjudgment avoidance strategies and power consumption optimization should be considered in software design.


Installation and commissioning

The installation position of the body sensing switch has an important effect on its performance. When installing, it is necessary to ensure that the sensor can cover the area to be detected and avoid interference with other metal objects or obstacles. At the same time, it is also necessary to consider the installation height and Angle of the sensor to maximize its detection effect.


After the installation is complete, you need to debug the system. During the debugging process, it is necessary to test the sensor's human detection performance at different distances, different angles and different environments to ensure that the system can work accurately and stably. In addition, the control output needs to be tested to ensure that the output module can perform the corresponding operation as expected.


Fourth, the advantages and application prospects of millimeter wave radar human sensor switch


Compared with the traditional infrared sensor switch, the human sensor switch of millimeter wave radar has the following advantages:


High sensitivity: millimeter wave radar can penetrate smoke, dust and other obstacles, non-contact detection of the human body, with high sensitivity.


High anti-interference: millimeter wave radar is not affected by environmental factors such as light and temperature, and can work stably in a variety of complex environments.


All-weather operation: Millimeter wave radar is not limited by day and night, and can detect human bodies all day long.


Based on the above advantages, millimeter-wave radar human sensor switch has broad application prospects in smart home, security monitoring, automation control and other fields. For example, in the field of smart home, the millimeter-wave radar human sensor switch can be applied to the intelligent lighting system to realize the automatic control of people to light up and people to walk off the light; In the field of security monitoring, it can be used for automatic alarm systems to monitor human activities in real time; In the field of automation control, it can be used for human body induction control of industrial automation production lines.


V. Conclusion


As a new kind of human body sensing technology, millimeter wave radar human body sensor has been widely used in many fields with its unique advantages. This paper describes in detail the principle of millimeter wave radar human sensor and the scheme of human sensor switch based on the principle, including hardware design, software design, installation and debugging. With the continuous progress of technology and the continuous expansion of application scenarios, the human sensor switch of millimeter wave radar will play a greater role in the future, promoting the rapid development of intelligent and automated control.
